065-P-1065 Series
Technical SpecificationsCAD modelMORE >Pipe Size 1/2", 3/4" Operation Pilot operated Type 3/2 Single Coil Internal Air Pilot O.P.D 21.8 to 174 psi (1.5 to 12 bar) Media Temperature 5°F to 149°F (-15°C to 65°C) Solenoid Enclosures Watertight & Dust protection: IP65
CNOMO size 30 interfaces for solenoid pilot valve
ISO 5599/1 subbase for 5/2 type-
065-P-2065 Series
Technical SpecificationsCAD modelMORE >Pipe Size 1/2", 3/4" Operation Pilot operated Type 3/2 Single Coil External Air Pilot O.P.D 21.8 to 174 psi (1.5 to 12 bar) Media Temperature 5°F to 149°F (-15°C to 65°C) Solenoid Enclosures Watertight & Dust protection: IP65
CNOMO size 30 interfaces for solenoid pilot valve
ISO 5599/1 subbase for 5/2 type
065-P-3065 Series
Technical SpecificationsCAD modelMORE >Pipe Size 1/2", 3/4" Operation Pilot operated Type 3/2 Pneumatic Control O.P.D 21.8 to 174 psi (1.5 to 12 bar) Media Temperature 5°F to 149°F (-15°C to 65°C) Solenoid Enclosures Watertight & Dust protection: IP65
CNOMO size 30 interfaces for solenoid pilot valve
ISO 5599/1 subbase for 5/2 type-
065-P-4065 Series
Technical SpecificationsCAD modelMORE >Pipe Size 3/4" Operation Pilot operated Type 5/2 Double Coil Internal Air Pilot O.P.D 21.8 to 174 psi (1.5 to 12 bar) Media Temperature 5°F to 149°F (-15°C to 65°C) Solenoid Enclosures Watertight & Dust protection: IP65
CNOMO size 30 interfaces for solenoid pilot valve
ISO 5599/1 subbase for 5/2 type -
065-P-5065 Series
Technical SpecificationsCAD modelMORE >Pipe Size 3/4" Operation Pilot operated Type 5/2 Double Coil External Air Pilot O.P.D 21.8 to 174 psi (1.5 to 12 bar) Media Temperature 5°F to 149°F (-15°C to 65°C) Solenoid Enclosures Watertight & Dust protection: IP65
CNOMO size 30 interfaces for solenoid pilot valve
ISO 5599/1 subbase for 5/2 type -
065-P-6065 Series
Technical SpecificationsCAD modelMORE >Pipe Size 3/4" Operation Pilot operated Type 5/2 Pneumatic Control O.P.D 21.8 to 174 psi (1.5 to 12 bar) Media Temperature 5°F to 149°F (-15°C to 65°C) Solenoid Enclosures Watertight & Dust protection: IP65
CNOMO size 30 interfaces for solenoid pilot valve
ISO 5599/1 subbase for 5/2 type
